Titanium Powder for 3D Printing

About this item:

Titanium Powder is a lustrous silver-grey powder. The method of 3D printing titanium, also known as direct metal laser sintering (DMLS), is an additive metal fabrication process. This process builds on the basic principles of 3D printing through the application of metallic materials for direct utility in just about any field that would need the use of such immediately developed technology.



A 3D printing titanium model is printed in titanium powder that is sintered together by a laser to produce end-use parts. 3D printed unpolished titanium model is a little grayer and more matte with a slightly rougher and less defined surface. However, 3D printing can produce a more complicated titanium model which traditional techniques could hardly achieve.



Spherical titanium powder for 3D printing now can be supplied. Sizes of our titanium powder can be customized upon your request.



Grades	GR1, GR5, GR5 ELI
Powder particle size	0-20μm, 15-45μm, 15-53μm, 53-105μm, 53-150μm, 105-250μm
Sphericity	Spherical or near-spherical, sphericity ≥0.90
Appearance quality	Visually silver-gray, without obvious oxidation color particles.
Oxygen content	≤1000ppm, can be customized ≤700ppm



There are two preparation processes for spherical titanium powder, the processes of electrosolitary and the gas atomization method; the spherical titanium powder prepared by electrosolar method has high sphericity, high density, good powder fluidity, metal impurities, and gas content Low characteristics, however, coarse-grained.



Titanium powder is mainly used in selective laser melting (SLM), electron beam melting (EBM), laser metal deposition (LMD), hot isostatic pressing (HIP), injection molding (MIM), etc.



Using 3D printing technology, we can design very complex parts while reducing product weight. The mechanical connectors printed by 3D technology have reduced the weight by 40% after the topology optimization, but the function and mechanical properties have not been weakened; the bone plate printed by 3D additive printing is more capable than the traditional standard bone plate According to the specific situation of the patient, solve the problems of not straight bone and poor fit. These designs are difficult to complete by traditional processing, but they are the advantages of 3D printing. Therefore, 3D printing is an effective supplement to traditional processing technology.



● High purity;

● High sphericity;

● Good liquidity;

● Corrosion resistance;

● High-temperature resistance;

● No magnetism;

● High strength.



3D Printing Powder, Spherical TA15 Titanium-Based Powder, Spherical TC4 Titanium-Based Powder, Spherical TC11 Titanium-Based Powder.

Spherical Titanium Powder Specification



Grade	Mainly composition(wt. %)	Impurities Max.
	Ti	Fe	C	N	H	O	Impurities
							Single	Sum
TA1	balance	0.2	0.08	0.03	0.015	0.18	0.1	0.4
TA2	balance	0.3	0.08	0.03	0.015	0.25	0.1	0.4
TA3	balance	0.3	0.08	0.05	0.015	0.35	0.1	0.4



Additive Manufacturing: Spherical Titanium Powder is widely used in the field of additive manufacturing or 3D printing.



Chemical Industry: Spherical Titanium Powder is used in the chemical industry for the production of various titanium-based compounds and catalysts.



Aerospace and Aviation: Spherical Titanium Powder is used in the production of aerospace components such as aircraft frames, engine parts, landing gears, and fasteners.



Medical Implants: Spherical Titanium Powder is used to create implants such as hip and knee replacements, dental implants, and prosthetic devices.



Powder Metallurgy: Spherical Titanium Powder is used in powder metallurgy applications, where it is blended with other metals or alloys to create sintered components. These components are used in industries like automotive, aerospace, and energy.



Coatings and Surface Treatments: Spherical Titanium Powder is used in coatings and surface treatments to provide enhanced corrosion resistance, wear resistance, and increased hardness to various materials and substrates.



Conductive Inks: Spherical Titanium Powder is used in the formulation of conductive inks for printed electronics and flexible circuitry applications. It enables the production of thin, lightweight, and flexible electronic devices.



Energetic Materials: Spherical Titanium Powder is used in the manufacturing of pyrotechnic materials and explosives due to its high reactivity and energy-release properties.



Product packaging:



This product is packed with inert gas, sealed, and stored in dry;



In a cool environment, it should not be exposed to the air;



Prevent oxidative agglomeration caused by moisture, which affects the dispersion performance and use effect;



Packaging quantity can be provided according to customer requirements.



Our Spherical Titanium Powder for 3D printing is tagged and labeled externally to ensure efficient identification and quality control. Great care is taken to avoid any damage which might be caused during storage or transportation.
