Inconel 625 Tube

Inconel 625 tube is with excellent resistance to pitting, crevice, and corrosion cracking.

Inconel 625 is highly resistant to a wide range of organic and mineral acids.



Excellent mechanical properties at both extremely low and extremely high temperatures.

Outstanding resistance to pitting, crevice corrosion, and intercrystalline corrosion.

Almost complete freedom from chloride-induced stress corrosion cracking.

High resistance to oxidation at elevated temperatures up to 1050C.

Good resistance to acids, such as nitric, phosphoric, sulfuric, and hydrochloric, as well as to alkalis makes possible the construction of thin structural parts of high heat transfer.

Other shapes of Inconel 625: sheet, plate, wire, flange, bar, rod

Related products: Inconel 600, Inconel 601.

environments, including high-temperature effects such as oxidation and carburization. Specification:

Material: UNS N06625

Standards: ASTM B444 ASTM B704 AMS 5581 BS3074 GEB50TF133

Chemical Composition, %



	Ni	Fe	Cr	Si	Mo	Mn	C
Max		5.0	23.0	0.50	10.0	0.50	0.10
Min	58.0		20.0		8.0



Environments, including high-temperature effects such as oxidation and carburization. Specification:

Material: UNS N06625

Standards: ASTM B444 ASTM B704 AMS 5581 BS3074 GEB50TF133

Chemical Composition, %



	Ni	Fe	Cr	Si	Mo	Mn	C
Max		5.0	23.0	0.50	10.0	0.50	0.10
Min	58.0		20.0		8.0

Oil and gas production where hydrogen sulfide and elementary sulfur exist at temperatures above 150C.

Components exposed to flue gas or in flue gas desulfurization plants.

Flare stacks on offshore oil platforms.

Hydrocarbon processing from tar-sand and oil-shale recovery projects.



Chemical Requirements
	Ni	Fe	Cr	Si	Mo	Mn	C
Max		5.0	23.0	0.50	10.0	0.50	0.10
Min	58.0		20.0		8.0

Mechanical Property Requirements
	Ultimate Tensile	Yield Strength (0.2% OS)	Elong. in 2 in. or 50mm or 4D, min., %	R/A	Hardness
Cold Worked/Annealed
Min	120 KSI	60 KSi	30
Max
Min
Max
Hot Worked/Annealed
Min	120 KSi	60 KSi	30
Max
Min
Max



Inconel 625 tube 625 is a popular nickel-chromium alloy that provides a high level of strength and ease of fabrication. It is known for several different unique properties. Inconel 625 is extremely resistant to a variety of unusually severe corrosive Applications:

• Components where exposure to seawater and high mechanical stresses are required.

• Structures in seawater applications and prone to high mechanical stress

• Oil and gas production

• Components in flue gas scrubbers

• Aerospace industry.
