Pure Tungsten Sheet
Item: Pure Tungsten Sheet
Material: 99% Pure Tungsten Plate/Sheet,
Purity: 99.95%, 99.99% and 9.999%
Standards: ASTM B760, GB3875-83
Product Introduction
About this item:
Pure tungsten sheets are highly esteemed for their outstanding characteristics, rendering them indispensable across diverse industries. With an exceptional ability to withstand high temperatures and corrosion, these plates are favored in aerospace and industrial settings. Their dense composition and robustness make them ideal for demanding applications like chemical processing and electrical components. Additionally, Tungsten Plates excel in medical and radiation shielding due to their effectiveness in attenuating radiation. Renowned for their versatility and reliability, Tungsten Plates remain the material of choice for tackling rigorous engineering tasks requiring durability and high performance.
Specifications
|
Product Name |
Tungsten Plate |
|
Purity |
W≥99.95% |
|
Process |
Rolling |
Tungsten Polished Plate Dimensions (Max, mm)
|
Thickness |
Width |
Length |
|
1.5-2.0 |
150 |
200 |
|
2.0-3.0 |
200 |
250 |
|
3.0-4.0 |
250 |
600 |
|
4.0-6.0 |
300 |
600 |
|
6.0-8.0 |
300 |
800 |
|
8.0-10.0 |
300 |
750 |
|
10.0-14.00 |
200 |
650 |
|
>14.0 |
200 |
500 |
Packaging
Our high-quality tungsten plates are tagged and labeled externally to ensure efficient identification and quality control. Great care is taken to avoid any damage during storage or transportation.
STM B760 chemical composition
|
Quality Standard (99.95% W) |
|||
|
Element |
Value ( |
Element |
Value ( |
|
Fe |
5 |
Mo |
10 |
|
Ni |
3 |
P |
1 |
|
Al |
2 |
C |
5 |
|
Si |
3 |
O |
3 |
|
Ca |
3 |
N |
3 |
|
Mg |
2 |
|
|
Thickness Tolerance
|
Standard Width inch (mm) |
Standard Thickness inch(mm) |
Thickness Tolerance inch (mm) |
|
≤12(305) |
0.005-0.010 (0.13-0.25) |
±0.001(±0.0254) |
|
12 |
>0.010-0.020 (0.25-0.51) |
±0.002(±0.0508) |
|
>12-24(305-610) |
>0.010-0.025(0.25-0.64) |
±0.0025(±0.0635) |
|
Tungsten Plate/Sheet /Foil |
||
|
Thickness(min) mm |
Width(max) mm |
Length(max) mm |
|
0.05 |
150 |
500 |
|
0.06~0.09 |
250 |
500 |
|
0.1 |
300 |
500 |
|
0.12 |
320 |
550 |
|
0.15 |
350 |
600 |
|
0.2~0.6 |
400 |
600 |
|
0.7~0.9 |
400 |
800 |
|
1~2 |
450 |
800 |
|
2~10 |
450 |
600 |
|
10~15 |
450 |
500 |
|
15~25 |
300 |
500 |
Applications
For producing electric light source parts, and components of electric vacuum; producing W-boats, heat shields, and heat bodies in high-temperature furnaces.
Pure tungsten sheets are used in the production of X-ray targets. The high density of tungsten makes it an ideal material for X-ray targets because it can absorb and dissipate the heat generated by the X-ray beam.
Tungsten sheet metals are also used in the aerospace industry for their high strength and resistance to corrosion. They are used as shielding material for spacecraft and satellites to protect them from the harsh radiation environment in space.
Other applications for 99% tungsten plates include the production of electrodes for welding and cutting, as well as for the manufacture of electrical contacts and heat sinks.
