Gr5 Titanium Strip

Item: Gr5 Titanium Strip
Standard: ASME B265
Thickness: under 4.75 mm / Customizable
Width: under 610mm / Customizable
Length: Up to 6000mm / Customizable
Finish: Hot Rolling, Cold Rolling.
Surface: Polished, Sandblasted, Acid Washing.
Payment: T/T

Send Inquiry

Product Introduction

Additional Information

Weight: According To The Actual Weight	Packaging: Sponge Padding + Wooden Crate
Certificate: ISO 9001:2015	Price Term: EXW, FOB, CIF
Transportation: Ocean, Land, Air	Place of Origin: Bao Ji, China(mainland)
Delivery Time: 5-25 days.

Tensile Requirements

Item	Tensile Strength, min	Yield Strength, min	Elongation, min
Grade 5	895 MPa	828 MPa	10 %

Note: The data in the table is for reference only and conforms to standard specifications. The actual parameters are subject to the factory inspection report. We guarantee that the purchased products must meet international standards.

Chemical Requirements

Gr5 Titanium Strip
UNS Number	R56400
Carbon,max.	0.08
Oxygen range or max.	0.2
Nitrogen,max.	0.05
Hydrogen,max.	0.015
Iron range or max.	0.4

Products Description

Gr5, commonly referred to as 6Al-4V, is a 2-phase alpha-beta type Titanium alloy. It is a grade used primarily for wrought products, such as Round Bars, Flat Bars, Rolled Plate, and Forged Products. It is produced in multiple melts starting with a vacuum arc remelt (VAR), electron beam (EB), or plasma arc hearth melt (PAM). Remelting is done in one or two steps in a VAR furnace.

In the annealed condition, its yield strength is 120 Ksi minimum. It is readily formed and weldable by using inert gas shielding. Spot, seam, flash, and pressure welding are also used depending on the application. Its strength properties can be elevated by solution treatment and aging (STA). This grade has good elevated temperature strength, low-temperature impact strength, and good creep resistance. 6Al-4V Titanium shows good corrosion resistance to seawater and marine atmospheres and in wet chlorine and chlorine dioxide. Machining is similar to that of Austenitic Stainless Steels, e.g. 304, 316. Slow speeds, heavy feeds, and non-chlorinated cutting fluid are typically used for most applications.

Our extensive inventory of ingot and billet allows us to support rolled plates, rounds, forged rounds, and open-die custom "on size" block forgings at less than mill lead time and no mill minimums. SSA also offers value-added processing such as heat treating, trepanning, water jet cutting, sonic inspection, and mechanical testing.

Gr5 titanium Strip applications

Airframe components

Military Hardware

Pressure vessels

Spacecraft components

(rocket engine)

Medical & surgical devices

Under the standards of ASME SB 265, AMS 4905, AMS 4911, and DMS 1592 standards, Gr5 Titanium Strips are also used to produce tubes and pipes as well.

Gr5 Titanium Strip also boasts a high level of safety, which is imperative in industries where human lives are at stake. The product is resistant to temperature extremes, chemical corrosion, and mechanical stress, ensuring that it performs optimally under extreme conditions.

Our Gr5 Titanium Strip is crafted to the highest standards, ensuring consistency in terms of quality, dimensions, and specifications. With its exceptional properties, our product can also be customized to meet your specific requirements and applications.
