Titanium Billet
Item: Titanium Billet
Standards: ASTM B348, ASME SB348, ASTM F67, ASTM F136, AMS 4928, MIL-T-9047.
Size Range: Φ15.0mm -500.0mm
Material: GR5/BT6/IMI318，BT20，Ti-6242S，BT9，Ti-6246，Ti-15333，GR19，Ti-8823，etc.
Quality Standard: AMS 4928, AMS 4967, ISO 5832
Application: Aviation, Aerospace, Military, Marine, Civil, etc.
Product Introduction
Our titanium billet products have round, square, or rectangular cross-sections, with an area equal to or greater than 16 square inches (103 cm squared). Billet can be made from either standard or premium quality ingots. Billet can be lathe-turned to a maximum length of 20 feet (6096 mm). West-Ti stocks titanium and other specialty metal billets available for any of your custom requirements.
Titanium Billets are all made from quality titanium ingots. Titanium bar products can meet various standards, including ASTM B348, ASME SB348, ASTM F67, ASTM F136, and AMS 4928. The grades can be CP titanium, Gr5, Gr6, Gr7, Gr12, and Gr23.
Usually, we have some most common bars in stock, such as Gr1, Gr2, and Gr5 bars. And we can offer prompt delivery worldwide if the bars you need are in stock. Regarding the detailed specifications, please check the following table.
Material
|
CP Titanium |
Gr1, Gr2 |
|
|
Gr5 |
Ti-6Al-4V |
|
|
Gr6 |
Ti-5Al-2.5Sn |
|
|
Gr7 |
Ti-0.2Pb |
|
|
Gr9 |
Ti-3Al-2.5V |
|
|
Gr12 |
Ti-0.3Mo-0.8Ni |
|
|
Gr23 |
Ti-6Al-4V ELI |
|
Weight list of the titanium bar
|
Diameter(mm) |
Weight(kg/m) |
Diameter(mm) |
Weight(kg/m) |
|
4.0 |
0.057 |
40.0 |
5.663 |
|
5.0 |
0.089 |
45.0 |
7.164 |
|
6.0 |
0.127 |
50.0 |
8.845 |
|
8.0 |
0.227 |
60.0 |
12.74 |
|
10.0 |
0.354 |
63.0 |
14.28 |
|
12.0 |
0.510 |
70.0 |
17.34 |
|
15.0 |
0.796 |
80.0 |
22.65 |
|
16.0 |
0.906 |
90.0 |
28.67 |
|
20.0 |
1.415 |
100.0 |
35.39 |
|
25.0 |
2.212 |
120.0 |
50.96 |
|
30.0 |
3.185 |
130.0 |
59.81 |
|
35.0 |
4.335 |
150.0 |
79.61 |
|
40.0 |
5.663 |
180.0 |
114.7 |
Applications
Aircraft structural parts
Ensure consistent performance of parts in all regions, and improve aircraft stability and safety.
More single output, and sufficient capacity, can achieve fast delivery.
Easy to lightweight design, realize overall weight reduction of aircraft, and reduce energy consumption.
Engine Blade
High thrust-to-weight ratio, high reliability, high durability,
Low fuel consumption, low cost
